Honeycomb Core Doors
1 3/4" standard; also available in 1 3/8"
Any manufacturer's hinge locations
18-gauge A60 galvannealed steel standard
Continuously welded vertical edges(seamless) standard
Rust inhibitive prime coat ANSI/SDI 250.10
Also available as a stock door
16-gauge,14-gauge and 12-gauge steel
G90 galvanized steel
Stainless steel
Resin impregnated honeycomb
Up to 3 hour fire label
Integral lite option
Integral louver option
Flush top cap
Any manufacturer's Deadlock prep,Panicprep,and Mortise sectional trim
Flat bar astragal(pairs)
3/6" for hinges
12-gauge for locks-standard
14-gauge for closers-standard
Heavier gauge reinforcements available
Steel Stiffened Doors
1 3/4” standard; other thicknesses available
Any manufacturer's hinge locations
18-gauge steel A60 galvannealed standard
20-gauge stiffeners spot-welded at 6" on center with fiberglass insulation
Continuously welded vertical edges(seamless) standard
Rust inhibitive prime coat ANSI/SDI 250.10
16-gauge,14-gauge,12-gauge,and 10-gauge steel
G90 galvanized steel
Stainless steel, available in 304 or 316 alloys
18-gauge stiffeners spot-welded
Up To 3 hour fire label
Integral lite option
Integral louver option
Flush top cap
Any manufacturer's Deadlock prep, Panicprep,and Mortise sectional trim
Flat bar astragal(pairs)
3/16” for hinges
12-gauge for locks standard
14-gauge for closers standard
Heavier gauge reinforcements available
Polystyrene Core Doors
1 3/4” standard; also available in 1 3/8”
Any manufacturer's hinge locations
18-gauge A60 galvannealed steel standard
Continuously welded vertical edges(seamless) standard
Rust inhibitive prime coat ANSI/SDI 250.10
Also available as a stock door
16-gauge,14-gauge and 12-gauge steel
G90 galvanized steel
Stainless steel
Up to 3 hour fire labe
Integrallite option
Integral louver option
Flush top cap
Any manufacturer's Deadlock prep, Panicprep,and Mortise sectional trim
Flat bar astragal(pairs)
3/16” for hinges
12-gauge for locks - standard
14-gauge for closers - standard
Heavier gauge reinforcements available
Temperature Rise Doors
1 3/4” standard;other thicknesses available
Any manufacturer's hinge locations
18-gauge steel A60 galvannealed standard
18-gauge top and bottom channels spot welded to face sheets
Continuously welded vertical edges(seamless) standard (open seam available)
60 -180 min.labels available for 450°,and 250° temp rise at 30 min.
Rust inhibitive prime coat ANSI/SDI 250.10
16-gauge and 14-gauge steel
G90 galvanized steel
Integral lite option, up to 100 sq.inches (only for 60 and 90 min.ratings)
Flush top cap
Any manufacturer's Deadlock prep,Panic prep,and Mortise sectional trim
Flat bar astragal(pairs)
3/16” for hinges
12-gauge for locks standard
14-gauge for closers standard
Heavier gauge reinforcements available
